Radiodetection Multifunction Signal Transmitter
Based on a fully digital platform, the Tx family of signal transmitters has been designed to complement Radio detection's advanced high-precision cable and pipe locators including the RD8200 and Marker Locator ranges
The Tx range is designed to meet the demands of tracing utilities through today’s complex underground infrastructure. The Tx-5 has a medium power and induction capability as well as Fault-Find. The Tx-10 has the highest power capability with both Fault-Find and CD modes as standard.
The transmitter range features locate frequencies compatible with locators across the Radiodetection Precision Locator ranges and can be easily customized to match your chosen locator using the ‘model’ feature.
All transmitters feature constant current across their entire bandwidth in all modes (direct connect, clamp, or inductive mode), and deliver convenience on-site with an IP65 ingress protection rating, removable accessory tray, and a large, high-contrast, backlit LCD screen.
iLOC is an advanced Bluetooth® link between the RD8200 locator and transmitter, which allows you to control the locate signal’s power and frequency from up to 1400’ / 450m away. Less time walking and more time locating.
High voltage output makes sure that you can get locatable signals onto even high-impedance lines like telephone pairs.
Apply a Fault-Find signal with the Tx-5 and Tx-10 transmitters and use an accessory A-frame to detect and pinpoint insulation faults.
The transmitter can be used to recommend a general-purpose locate frequency for the intended locate task by measuring the impedance of the target cable or pipe. SideStepAuto helps to improve locate accuracy and extends battery life.
Transmit you're located signal as far as possible by automatically matching the transmitter impedance to that of your target cable.
Deliver extended run-time, lighter weight, and superior cold-weather performance by comparison to standard alkaline batteries.
No need for operators to replace, manage and recycle alkaline battery cells, reducing the associated costs, workload, and environmental burden.
Shock-resistant, ingress-protected casing protects against knocks, drops, water, and dust.
Extend alkaline battery life by enabling ECO mode. When a low battery condition is detected the transmitter gradually reduces the power output and provides audio and visual warnings.
Measure output voltage, line voltage, current, impedance, and power, and characterize faults on the target line before beginning a survey
Accessories to optimize the system to your needs
