Features:

Robust, motor-powered levelling
Inclinations in one or two axes with convenient % input for X and Y axes with 3 decimal places.
Temperature Control: Automatic temperature compensation
Segment Control
PlaneLock X/Y: the tilt level is not monitored by the tilt sensor, but by COMMANDER 3. Advantageous in continuous use.
AutoTarget function (Y-axis) for automatic axis alignment
FindX: simple and precise alignment of the X-axis
AutoAlign: Automatic alignment of the laser beam to the receiver. In the horizontal plane for measuring and storing the slope of the terrain in both axes (X and Y). In the vertical plane, ideally suited for batter board application and facade construction.
Tilt control: the position of the laser plane is continuously monitored in the slope mode and re-levelled if necessary.
Slope value once input is stored beyond switch-off
Automatic level control stops the laser if it receives a heavy jolt. In this way, height errors are avoided.
Available with highly visible high-power laser diode (laser class 3R) or with bright beam technology (laser class 2)
COMMANDER 3 with large reception field. For complete remote control of the PRIMUS 3
Large, clear display showing inclination, rotation speed, battery level, etc.

Technical data

View Brochure

Levelling accuracy	± 0.5 mm/10 m
Self-levelling range	approx. ± 8.5° motor-powered, with automatic level control
Setting of slope function (x/y-axis)	± 15%
Accuracy of the slope function	better than ± 0.015%
Working range Ø	approx. 700 m with receiver COMMANDER 3
Laser	< 5 mW, laser class 3R, 635 nm or < 1mW, laser class 2, 635 nm
Working range radio remote control	up to 150 m
Working range AutoAlign	up to 150 m
Rotating speed	600 rpm, 900 rpm or 1200 rpm
Protection class	IP 67
Power supply	Li-ion rechargeable battery
Operation duration	up to 40 h
Connecting thread	5/8’’
